Hikvision DS-1LN6U-SC0 Cat6 UTP Cable
- Brand: Hikvision
- Model: DS-1LN6U-SC0
- Standard: ISO/IEC11801
- Dia meter 6.00±0.30 mm
- 4PR 23AWG 75
- Color: Orange
- Warranty: No Warranty
- Category Cat.6
- Steath Printing HIKVISION 4PR 23AWG 75? U/UTP CAT6 VERIFIED TO ANSI/TIA-568-C.2 PVC ****m mm/dd/yyyy Tracing Code-HS
- Reference Standard ISO/IEC11801, ANSI/TIA-568-C.2,RoHS 2.0
- Fire Resistance No
- Conductor Solid-Bare Copper (99.95%);0.55±0.005 mm,23 AWG
- Insulation HDPE;0.98±0.05 mm
- Rip-Cord Yes
- Separator Yes
- Sheath Physical Properties
- Before Aging Tensile strength ≥ 13.5 Mpa; Elongation ≥ 150%
- Aging Period 100? × 24h × 10d
- After Aging Tensile strength ≥ 12.5Mpa; Elongation ≥ 125%
- Cold Bend -20 ± 2? × 4h,8 × cable O.D, no visible cracks
- Electrical Characteristics (20?)
- 1.0-250.0 MHz Impedance 100 ± 15Ω @ ≤ 100MHz;100 ± 25Ω @ 100-250MHz
- 1.0-250.0 Mhz Delay Skew≤ 45 ns/100 m
- DC Resistance ≤ 9.38 Ω/100 m
- DC Conductor Resistance Unbalance ≤ 5.0 %
- Package Dimension: 400 mm (W) × 400 mm (H) × 240 mm (D)(15.75″ × 15.75″ × 9.45″)
- Weight 12.3 ± 0.5kg
- Cable Length (305 ±1.5) m
- Ambient Temperature -20 ? to 75? (-4? to 167?)
- Operating Voltage 60 V
- Sheath Thickness 0.5±0.10 mm
- Material PVC
- Color Orange
- Dia meter 6.00±0.30 mm
