SKU: AYT-93E2C2C90B
পরিমাণ
<h3>Key Features:</h3>• 1/3″ SONY 2MP CMOS Sensor • 2.0 Megapixels • 20X Optical Zoom • 3D DNR, HLC/BLC • Low Bitrate, Excellent low light performance • Weatherproof IP66
| CAMERA | |
| Image Sensor | 1/3″ SONY 2MP CMOS Sensor |
| Max Resolution | 1920×1080 |
| Effective Pixels | 2.0 Mega Pixels |
| Optical Zoom | 20x Zoom |
| Compression Standard | H.264 |
| Maximum Frame Rate | Up to 30 fps |
| Bit Rate | 128Kbps～10Mbps |
| Illumination | 0 Lux (IR ON) |
| Focus Control | Auto/Manual |
| Focus Length | 4.7±5%～94±5%mm，Optical Zoom 20X |
| Infrared | 9Pcs High Power Array LED |
| IR Distance | ≥100m. |
| FUNCTION | |
| OSD | Support |
| DWDR | Support |
| Smart Defog | Support |
| ROI | Support |
| Privacy Mask | Support 4 Rectangle Areas |
| Motion Detection | Support |
| Video Adjust | Supports Contrast, Brightness, Saturation, Sharpness Adjustment |
| Audio | Support |
| Image Setting | Mirror, Rotate |
| Alarm | E-mail, Client |
| Network Protocols: | HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, CloudSEE. |
| System Compatibility | ONVIF 2.4 |
| Remote Operation | System, Stream, User, Network, Management, PTZ Function |
| PTZ | |
| Pan/Tilt Range | Pan: 0°～360°; Tilt: 0°～90° |
| Pan Speed | 0.6°～200°/S |
| Tilt Speed | 3.5°～35°/S |
| Manual Speed | High, Middle, Low |
| Number of Preset | 128 |
| Patrol | Up to 8 Patrols, 32 Presets/Patrol |
| Scan | Pattern Scan, Tilt Scan, Frame Scan, Random Scan |
| Control | RS485 |
| COMMUNICATION | |
| Communication Protocol | Pelco-D |
| Communication interface | RS485 |
| Baud Rate | 1200/2400/4800/9600bps |
| NTERFACE | |
| Ethernet | 1 RJ45 10M / 100M Ethernet |
| Audio I/O | 1ch Audio In |
| General | |
| Power Supply | DC12V |
| Power Consumption | Day：15W; Night：＜36W |
| Operating Temperature | -20°C ~ +60°C |
| Operating Humidity | 10% – 90% Rh Non-Condensation |
| Ingress Protection | IP66 |
| Product Dimensions | 290x290x450mm |
| Product Weight | 5.5Kg |
