<p>1/3″Progressive Scan CMOS</p><p>• 4.0 Megapixels</p><p>• 25X Optical Zoom</p><p>• With Starlight function</p><p>• 3D DNR, HLC/BLC</p><p>• Humanoid Intelligent Tracking</p><p>• Weatherproof IP66</p>
| CAMERA | |
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Max Resolution | 2496×1440 |
| Effective Pixels | 4.0 Mega Pixels |
| Optical Zoom | 25x Zoom |
| Compression Standard | H.264/H.265 |
| Maximum Frame Rate | Up to 25 fps |
| Bit Rate | 267Kbps～8Mbps |
| Illumination | 0 Lux (IR ON) |
| Focus Control | Auto/ Semi-auto/ Manual |
| Focus Length | Optical Zoom 25X |
| Infrared | 4 infrared lights + 4 laser lights |
| IR Distance | ≥120m. |
| FUNCTION | |
| OSD | Support |
| DWDR | Support |
| Smart Defog | Support |
| ROI | Support |
| Privacy Mask | Support 24 area occlusion, single screen supports up to 8 occlusion areas |
| Motion Detection | Support |
| Video Adjust | Supports Contrast, Brightness, Saturation, Sharpness Adjustment |
| Audio | Support audio monitoring, intercom |
| Image Setting | Mirror, Rotate |
| Alarm | E-mail, Client |
| Network Protocols: | HTTP, TCP/IP, ICMP, RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS, CloudSEE. |
| System Compatibility | ONVIF 2.4 |
| Remote Operation | System, Stream, Alarm , Network,Storage，Management, PTZ Function,Insight |
| PTZ | |
| Pan/Tilt Range | Pan: 0°～360°; Tilt: 0°～90° |
| Pan Speed | 0°～30°/S |
| Tilt Speed | 0°～20°/S |
| Manual Speed | High, Middle, Low |
| Number of Preset | 1024 |
| Patrol | Up to 2 Patrols |
| Scan | Patrol Scan, Pattern Scan, Tilt Scan, Frame Scan, Random Scan |
| Control | RS232 |
| COMMUNICATION | |
| Communication Protocol | Pelco-D |
| Communication interface | RS232 |
| Baud Rate | 1200/2400/4800/9600bps |
| NTERFACE | |
| Ethernet | 1 RJ45 10M / 100M Ethernet |
| Audio I/O | 1ch Audio In |
| General | |
| Power Supply | DC12V/3.33A |
| Power Consumption | ≤ 25W |
| Operating Temperature | -20°C ~ +60°C |
| Operating Humidity | 0% – 93% Rh Non-Condensation |
| Ingress Protection | IP66 |
| Product Dimensions | 205x 325X389 (mm) |
| Product Weight | ≤ 2490(g) |
